WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features two 100mm unique blade fans, the heatpipe directly touches the GPU, alternate spinning, 3D active fan and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase air pressure. GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.
SCREEN COOLING
Extended heatsink design allows air flow to pass through, providing better heat dissipation.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.
ULTRA DURABLE
ULTRA COOLING
Lower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.
LOW POWER LOSS
Metal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.
LONGER LIFE
Lower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespan.
PROTECTION BACK PLATE
The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
Key features:
- NVIDIA Ampere Streaming Multiprocessors
- 2nd Generation RT Cores
- 3rd Generation Tensor Cores
- Powered by GeForce RTX™ 3050
- Integrated with 8GB GDDR6 128-bit memory interface
- WINDFORCE Cooling SystemProtection back plate
Specifications:
Graphics Processing: GeForce RTX™ 3050
Core Clock: 1792 MHz (Reference Card: 1777 MHz)
CUDA® Cores: 2560
Memory Clock: 14000 MHz
Memory Size: 8 GB
Memory Type: GDDR6
Memory Bus: 128 bit
Card Bus: PCI-E 4.0
Digital max resolution: 7680x4320
Multi-view: 3
Card size: L=243.6 W=124.8 H=40.2 mm
PCB Form: ATX
DirectX: 12 Ultimate
OpenGL: 4.6
Recommended PSU: 450W
Power Connectors: 8 pin*1
Output: DP1.4*1
HDMI 2.1*1
Dual-Link DVI-D*1Accessories: Quick guide
